Fabrieksspecificatie onderhoud Lexus GS300 (1998-2000)

Motorolie (verversingsinterval afhankelijk van gebruik en type olie):
Automatische transmissie*:
Verlichting:
A = HB3 Halogeenlamp
B = D2R Gasontladingslamp
C = HB4 Halogeenlamp
D = Glassokkellamp
Bougies:

Motorolie (verversingsinterval afhankelijk van gebruik en type olie):
- Aftapbout vastdraaien met 37Nm
- inhoud met oliefilter 5,5L
- zonder oliefilter 5,2L
- type: API SH "Energy-Conserving II", SJ "Energy-Conserving" multigrade-motorolie of ILSAC multigrade.
- aanbevolen viscositeit (SAE) bij te verwachten temperatuurbereik (graden celcius) tot volgende verversing:
-07/38+ = 20W-50
-12/38+ = 15W-40
-18/38+ = 10W-30
-30/10 = 5W-30*
(*) bij extreme vriestemperatuur wordt 5W30 aanbevolen i.v.m. soepel starten.-12/38+ = 15W-40
-18/38+ = 10W-30
-30/10 = 5W-30*
Automatische transmissie*:
- inhoud totaal: 8.2L
- (deel)verversing: 1.9L
- vloeistof: Toyota IV ATF of gelijkwaardig alternatief (Mobil ATF 3309, Kroon SP 2062)
- fabrikant: AISIN Warner >> zie specs type A650E, 5 speed
- ATF (deel)verversen DIY: viewtopic.php?f=96&t=4263
- volume: 1.35 Liter
- type: Hypoid-olie API GL-5
- viscositeit: boven -18 gr. cels. SAE90, beneden -18 gr. cels. SAE80W of SAE80W-90
- Differentieel Olie verversen DIY: viewtopic.php?f=96&t=4822
- type: SAE J1703 of FMVSS Nr. 116 DOT 3 (eventueel DOT 4 of 5.1)
- type: AT DEXRON II of III
- inhoud: 7,7L
- type: Ethyleen-glycol koelvloeistof (Long Life Coolant)
- velgmaat 16'' x 7,5JJ, bandmaat 225/55 R16 94V
- (optioneel) velgmaat 17'' x 8, bandmaat 235/45/17
- 103Nm wielmoeren aanspannen
- maximaal belast: voor 3.0, achter 3.4
- <= 4 personen: voor 2.4, achter 2.6
- maximaal belast: voor 2.4, achter 2.6
- <= 4 personen: voor 2.2, achter 2.2
Verlichting:
- gasontladingslamp, type B, 35W (dimlicht)
- halogeenlamp, type C, 51W (dimlicht)
- Verstraler, type A, 60W
- Richtingaanwijzer zijkant, type D, 5W
- Richtingaanwijzer voor, type D, 21W
- Parkeerlicht, type D, 5W
- Mistlamp voor, type C, 51W
- Kentekenplaat, type D, 5W
- Mistachterlicht, type D, 21/5W
- Achteruitrijlicht, type D, 21W
- Richtingaanwijzer achter, type D, 21W
- Rem-/achterlicht, type D, 5/21W
A = HB3 Halogeenlamp
B = D2R Gasontladingslamp
C = HB4 Halogeenlamp
D = Glassokkellamp
Bougies:
- DENSO PK20TR11 of Denso referentielijst
- NGK BKR6EKPB11
- elektrodenafstand: 1.1mm
- Inhoud tank: +/- 75L
- benzine: 95RON of hoger, loodvrij
- Knoopcel autosleutel: CR1616
